Anton Bauer Titon Range V-Mount Lithium-Ion Battery 90Wh / 150Wh

Product type: Battery

Vendor: Anton Bauer



Add to the wishlist


Anton Bauer Titon Range Gold & V-Mount Lithium-Ion Battery

Product Highlights

  • The Titon batteries are available in both 90Wh and 150Wh models.
  • V Mount & Gold Mount
  • Supports up to 10A Continuous Draw
  • 12A Peak Draw for 5 Seconds
  • LCD Battery Capacity Gauge
  • D-Tap and USB Accessory Ports

Anton Bauer TITON Overview

Providing a basic power readout and no user interactive surfaces, the Anton Bauer Titon Lithium-Ion Battery can be used to power your Gold / V mount camera or other pro video gear. The lightweight lithium-ion chemistry can provide up to 10 amps of current on a continuous draw and support peaks of up to 12.5 amps for five seconds. At the side of the chassis, an LCD display screen shows battery capacity in percent remaining, and when put under load it shows the exact remaining runtime. Using the D-Tap and USB ports you can power essential accessories on your rig or other small electronics.

For those who prefer a basic battery without multiple display window options and mode selections. Additional information can be accessed and displayed via select Anton Bauer chargers (not included).
The built-in display shows remaining power as percent. When the battery is connected to a camera or light, or otherwise put under load the display changes to show the remaining runtime. This information is available in most professional camera EVFs.
The Titon Gold mount battery supports a continuous 10A total draw between the Gold / V mount, D-Tap, and USB ports. It will support a 12.5A draw for up to five seconds to accommodate the high-power draw (power inrush) of devices when they start up. The battery capacity is either 92Wh or 156Wh
The battery uses high-quality cells and robust electronics for power distribution and safety.
It has a working temperature range of -4 to 140°F, although temperatures below 40°F can greatly reduce battery performance.
The case is made from an ABS/polycarbonate blend.
You can also use other Anton Bauer chargers, as well as common competitive chargers; however, not all features and modes may be accessible with these other charges.


TITON 90 / 150
Capacity 92Wh / 156Wh

3.9 x 5.2 x 2.3" / 9.9 x 13.1 x 5.8 cm

3.9 x 5.2 x 2.6" / 9.9 x 13.1 x 6.5 cm

Weight 0.8kg / 1.1kg
Operating temperature range – Charge  32°F to +113°F (0°C to +45°C)
Operating temperature range – Discharge New Header -4°F to 140°F (-20°C to +60°C)
Maximum Discharge Rate 10A
Output Voltage Nominal 14.2V Operating 10.0V – 16.3V
